Basic Info.
|
Model NO. |
NY4150black |
|
Feature |
Wear-resistant, Heat-resistant, Insulating, Cold-resistant |
|
Raw Materials |
Synthetic Rubber, fiber,Carbon black |
|
Medium |
Oil Seal |
|
Performance |
Oil Resistant Non-Asbestos Rubber Sheet |
|
Color |
Black Rubber Sheet |
|
Certificate |
ISO9001 |
|
Applicable Medium |
Oil Resistance, Water Resistance,Water vapor |
|
Main Material |
Fiber, NBR |
|
Temperature Range |
-50-150ºC |
|
Transport Package |
Wooden Box |
|
Specification |
1530*1500/1530*1000/1530*4580/1530/4100 |
|
Trademark |
BTT |
|
Origin |
China |
|
Production Capacity |
600t/Year |
Packaging & Delivery
|
Package Size |
1550.00 * 1550.00 * 300.00mm |
|
Package Gross Weight |
300.000kg |
Product Description
This product is a non-metallic material, mainly composed of ultrafine fillers, nitrile rubber as the binder, organic and inorganic fibers, and is formed by steam rolling through the rolling method. Oil-resistant, water-resistant, steam-resistant, and resistant to common acids and alkalis. The operating temperature ranges from -50℃ to 150℃.
Main thickness: 0.4-5mm, 5.0mm above the board can be bonded.
colors: black
The product thickness is greater than 1.0mm clip-on steel wire.
T MAX:150℃
P MAX:4MPA
Product drawing
Production process
Sample
consignment
